Spitfire – Maintenance Manual
219
AP-74096, Rev. 1.0, 09/06/05
Firmware installation will take about 60 seconds. The following messages will appear in order on
the LED display on the operation panel during installation.
¾ “Loading"
¾ "Erasing"
¾ "Copying"
¾ "Comparing"
¾ "End"
Step 5 : Check if the buzzer sounded and whether the firmware was installed correctly.
Step 6 : Power the unit OFF.
Important :
After installation of the firmware onto the Spitfire, you must upgrade the heater
system board.
(3) Updating the heater system board
To update the heater system board of a Spitfire, please follow the instructions mentioned below.
Important :
¾ Before updating the heater system board, make sure you already installed the
firmware into the Spitfire.
Step 1 : Make sure the printer is OFF.
Step 2 : Press simultaneously the [CANCEL] and the [ENTER] key while turning the printer ON.
Step 3 : The display will mention the following message.
* User Setting *
Rem Update
F2 →
CRD Update
(1/1)
Step 4 : Press the [F2] key.
Step 5 : The heater system board is now being updated. The display will mention the following
messages.
Erasing sectors
Wait flash programming
Step 6 : At the end the display will mention the following message.
Card Update
DO NOT POWER DOWN
Version Installed
Step 7 : Press the [CANCEL] key.
Step 8 : Power OFF the unit.
Step 9 : Updating the heater system board is completed.
