Spitfire – Maintenance Manual
279
AP-74096, Rev. 1.0, 09/06/05
3 E 016 error
CPU Err [00]
Interruption
exception error:
Trouble occurred in
the interrupt process
4 E 016 error
CPU Err [02]
Command boundary
exception errors:
Trouble occurred in
the command
boundary.
5 E 016 error
CPU Err [03]
Data boundary
exception errors :
Trouble occurred in
the data boundary.
6 E 016 error
CPU Err [04]
Address exception
error (load or
command fetch):
Address error
occurred while
loading or fetching
commands.
7 E 016 error
CPU Err [05]
Address exception
error (store) :
Address errors
occurred while
saving.
8 E 016 error
CPU Err [06]
Address exception
error (command
fetch): Address
errors occurred
while loading or
storing commands
9 E 016 error
CPU Err [07]
Bus exception
errors (Loading and
storing): buss errors
occurred while
loading and storing
commands
10 E 016 error
CPU Err [08]
System call
exception errors:
System call trouble
occurred.
11 E 016 error
CPU Err [09]
Break point
exception error:
trouble occurred in
the break points.
12 E 016 error
CPU Err [10]
Reservation
command exception
errors: trouble
occurred in the
reservation
commands.
13 E 016 error
CPU Err [03]
Disable co-
processor exception
errors: trouble
occurred in the co-
processor.
14 E 016 error
CPU Err [12]
Calculation overflow
exception errors:
overflows occurred.
(1) Check the AC
power source and
the printer
peripheral
devices(2) Check if
the error recurs. If
not, check by
powering-up the
product several
times.
(3) The Mainboard
assembly may
have a problem.
• Replace
Mainboard
assembly
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV
board assembly
and cooling fan
assembly.
