Spitfire – Maintenance Manual
280
AP-74096, Rev. 1.0, 09/06/05
15 E 016 error
CPU Err [13]
Trap exception
errors : trap
occurred
16 E 016 error
CPU Err [15]
Floating point
exception error :
trouble occurred in
the floating points
17 E 016 error
CPU Err [22]
Watch exception
error : trouble
occurred in the
watch.
18 E 016 error
CPU Err [32]
Watch dog timeout
exception error :
watch dog time out
occurred.
19 E 016 error
CPU Err [33]
Abort error : Aborts
occurred
Notes :
¾ For the settings on a computer, refer to the computer's operation manual.
(2) Mechanical system critical errors
No. Message Phenomenon Check point Action Refer to
1 E065 error PF
motor
Trouble occurred in
the PF motor (X-
axis) during
operation.
Displayed when the
motor commended
value and feedback
from the encoder
are significantly
different.
(1) Check error
history from “Test:
history” of self-
diagnosis function.
→ History menu
2 E067 error
Paper feed
encoder
Trouble occurred on
paper travel (x-axis)
during operation.
Displayed when
there is no feedback
from the encoder.
(2) Set endurance
running cycles to
50 or more from
“Life: PF motor “ of
self-diagnosis
function and check
if X-axis motor
error is issued.
• Check
connection of
following
connectors in
Mainboard
assembly:
→ PF motor cable
assembly
connector J157
→ PF_ENC
assembly
connector J154
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV
board assembly
and cooling fan
assembly.
3 E069 error
Paper feed
timeout
Timeout occurred
on paper travel (X-
axis) during
operation.
Displayed when the
pressure roller has
not reached the
commanded
position.
(3) Check
“Encoder:PF”
under “Test:
Encoder” of self-
diagnosis function.
→ Encoder Menu
To Next Page
