Spitfire – Maintenance Manual
286
AP-74096, Rev. 1.0, 09/06/05
(2) The Mainboard
assembly may
have a problem.
• Replace the
Mainboard
assembly.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV
board assembly
and cooling fan
assembly.
(1) Check the
operation of the
transmission
photosensor for
the lever up/ down
via “Check: sensor
“ of the self-
diagnostic
function.
• Replace the
transmission
photosensor at the
lever.
→ Replacing the
transmission
photosensor.
(2) Is the
transmission
photosensor at the
lever motor
securely installed?
• If the
transmission
photosensor is
detached, fix it
securely.
→ Replacing the
transmission
photosensor.
(3) Is the sensor
element of the
transmission
photosensor at the
lever motor
contaminated?
• Clean the sensor
element using
cotton swabs.
→ Replacing the
transmission
photosensor.
(4) Is the
transmission
photosensor cable
at the lever motor
securely installed?
• Securely connect
the cable for the
transmission
photosensor cable
to Mainboard
assembly
connectors J123
and J124.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV
board assembly
and cooling fan
assembly.
16 E 080 Error
Lever Sensor
Trouble occurred in
the lever sensor.
(5) The Mainboard
assembly may
have a problem.
• Replace the
Mainboard
assembly.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV
board assembly
and cooling fan
assembly.
→ Counter
Initialization
Menu.
17 E 081 Error
Cap Sensor.
Trouble occurred in
the cap sensor.
(1) Check the
operation of the
transmission
photosensor at the
cap via “Sensor:
Head Lock” of the
self-diagnostic
function.
• Replace the
transmission
photosensor at the
cap.
→ Replacing the
transmission
photosensor.
