Spitfire – Maintenance Manual
287
AP-74096, Rev. 1.0, 09/06/05
(2) Is the
transmission
photosensor at the
cap securely
installed?
• If the
transmission
photosensor is
detached, fix it
securely.
→ Replacing the
transmission
photosensor.
(3) Is the sensor
element of the
transmission
photosensor at the
cap contaminated?
• Clean the sensor
element using
cotton swabs.
→ Replacing the
transmission
photosensor.
(4) Is the
transmission
photosensor cable
at the lever motor
securely installed?
• Securely connect
the cable for the
transmission
photosensor cable
to Mainboard
assembly
connectors J123
and J124.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV
board assembly
and cooling fan
assembly.
(5) Make sure that
the connections of
the SLIDE motor
assembly for
maintenance U/D
are good.
• Replace the
SLIDE motor
assembly for the
maintenance U/D.
→ Replacing the
SLIDE motor
assembly (wiper
arm).
(6) The Mainboard
assembly may be
damaged.
• Replace the
Mainboard
assembly.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV
board assembly
and cooling fan
assembly.
(1) Check the
up/down operation
of he cap (wiper)
via “Sensor: Head
Lock” of the self-
diagnostic
function.
• Replace the
transmission
photosensor at the
wiper.
→ Replacing the
transmission
photosensor.
(2) Is the
transmission
photosensor at the
wiper up/down
area securely
installed?
• If the
transmission
photosensor is
detached, fix it
securely.
→ Replacing the
transmission
photosensor.
(3) Is the sensor
element of the
transmission
photosensor
contaminated?
• Clean the sensor
element using
cotton swabs.
→ Replacing the
transmission
photosensor.
18 E 082 Error
Wiper Sensor
Trouble occurred in
the wiper sensor.
(4) Is the
transmission
photosensor cable
securely
connected?
• Securely connect
the cable for the
transmission
photosensor cable
to Mainboard
assembly
connector J131.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV
board assembly
and cooling fan
assembly.
