Spitfire – Maintenance Manual
299
AP-74096, Rev. 1.0, 09/06/05
(10) The Mainboard
assembly may have
a problem.
• Replace the
Mainboard
assembly.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV board
assembly and
cooling fan
assembly.
(1) Check the head
and CR cables for
skewed insertion.
• Redo the
connections of the
following
connectors.
Connectors for the
print head.
• CR board : J201 –
J232
• Mainboard : J137 -
J152
→ Replacing the
print head assembly
and head tape
power cable.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV board
assembly and
cooling fan
assembly
(2) The head and
CR cables may be
damaged.
• Replace the CR
tape power cables.
→ Replacing the
steel bearer, tube
bearing, CR tape
power cable and ink
tube.
(3) The print head
assembly may be
damaged.
• Replace the print
head assembly.
→ Replacing the
print head assembly
and head tape
power cable.
(4) The CR board
assembly may have
a problem.
• Replace the CR
board assembly.
→ Replacing the CR
board assembly.
(5) The HEAD_DRV
assembly board
may be damaged.
• Replace the
HEAD_DRV
assembly board
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV board
assembly and
cooling fan
assembly
7 Drawn black on a full screen (Or
other specified colour)
(6) The Mainboard
assembly may have
a problem.
• Replace the
Mainboard
assembly.
→ Replacing the
Mainboard
assembly,
HDD_Extension
board assembly,
HEAD_DRV board
assembly and
cooling fan
assembly
8 Light and slade printing occurs. (1) Check if the use
conditions are within
the normal
operation
conditions.
• Be sure to use the
product under the
guaranteed
operation
conditions.
-
