Spitfire – Maintenance Manual
49
AP-74096, Rev. 1.0, 09/06/05
Step 4 : Remove the 2 screws on the left cover spindles.
2 = Screws (M3x8) right cover spindles
Step 5 : Loose (not remove ! ) the 2 screws of the right spindle a little.
1 = E ring 2 = Screws (M3x8) left cover spindles
Step 6 : Remove the sensor assy.
