MUTOH spitfire 90 - Page 71

Spitfire – Maintenance Manual
71
AP-74096, Rev. 1.0, 09/06/05
46 J146 (87) 30 White or black CR board Lock type
47 J147 (87) 30 White or black CR board Lock type
48 J148 (87) 30 White or black CR board Lock type
49 J149 (87) 30 White or black CR board Lock type
50 J150 (87) 30 White or black CR board Lock type
51 J151 (87) 30 White or black CR board Lock type
52 J152 (87) 30 White or black CR board Lock type
53 J153 5 Black Free
54 J154 5 White PF_ENC
55 J155 3 White Cover R sensor
56 J156 3 Black Cover L sensor
57 J157 2 White PF motor Lock type
58 J158 3 White CR motor Lock type
59 J159 4 White Lever motor Lock type
60 J160 4 White Pump 1 motor
61 J161 5 White Pump 2 motor
62 J162 6 White HEAD U/D motor
63 J163 7 White Maintenance U/D motor
64 J164 4 White Wiper motor
65 J165
66 J167 7 White Interf. Cable Db9-Jst
Step 16 : Remove the mainboard assembly by loosening the 6 screws and 4 hexagon spacers.
Step 17 : To install new mainboard, please follow the procedure backwards.
