Feature Descriptions
MDM9000 Satellite Modem
Parameter Value Description
The AUPC range is then defined as
Max Power Control - Nominal power
Control. It is recommended that this
range does not exceed 10 dB.
For example: If the Nominal Output Power value is -25
dBm and the Max Power Control is -22 dBm, a power
compensation of maximum 3 dBm is possible during
fading.
Note that this value depends on the BUC specifications,
the MODCOD settings and the frequency band you are
operating in.
Maximum power
step up
dBm/100 ms
Typically set this
value to 0.1
dBm/100 ms
This step up value defines how fast fading will be
compensated.
In other words, how much dBm (power) is added per
second by the controller during fading. (Refer to the figure
below.)
Note: If the step up value is too high, this
could cause overshoot which will violate
the PEB.
Typically set this value to 0.1 dBm/100
ms.
