How to Manage the Device
MDM9000 Satellite Modem
Functional Blocks
Description
Device Management Displays general information on the status of the device.
• Uptime
• CPU Load
BBF over IP IN Functional block that allows to configure and monitor the incoming
traffic.
Encapsulation
Displays the configuration, how the incoming traffic is
encapsulated. This can be split up into the following, traffic
classification, traffic shaping, logical channel definition and then
the actual encapsulation of the shaped traffic.
The following encapsulation protocols are possible:
• BBF Encapsulation
– GSE (Generic Stream Encapsulation)
– XPE (Extended Performance Encapsulation)
• TS Encapsulation
– MPE (Multi Protocol Encapsulation)
– ULE (Ultra Lightweight Encapsulation)
S2 Extensions
Demodulator
(Demod Hardware option
Ordering nr. DH-02)
Displays the configuration, how the RF signal is taken into the
device. For example:
• Mode selection,
DVB-S2, DVB-S2X or S2
Extensions
• Symbol Rate
• Input Frequency • Input Level
DVB Demodulator
(Demod Hardware option
Ordering nr. DH-01)
Displays the configuration, how the RF signal is demodulated.
For example:
• Mode selection, DVB-S2 • Symbol Rate
• Input Frequency • Input Level
Decapsulation
Displays the configuration, how the encapsulated BBFs are
decapsulated.
• Filter ISI • Label Filter
• Label
