How to Manage the Device
MDM9000 Satellite Modem
Functional Blocks
Description
BBF Over IP OUT Functional block that allows to configure and monitor the
outgoing traffic.
Modulator
Displays the configuration information on how the traffic must be
modulated. For example:
• Mode selection, DVB-S2 or S2 Extensions
• Transmit (on/off)
• Output Frequency
• …..
Note that it is possible to control the Transmit
(Off/On) from the overview tab.
