2KZ/2K0
2-3-15
YC15
B11 MKCNT O PWM Chager roller control voltage (Black)
Connected to
high voltage
PWB
B12 MMCNT O PWM Chager roller control voltage (Magenta)
B13 BKBACCNT O PWM Developing AC bias control voltage
(Black)
B14 HVCLKK O 0/3.3 V DC (pulse) Developing bias clock signal (Black)
B15 HVCLKM O 0/3.3 V DC (pulse) Developing bias clock signal (Magenta)
B16 24VIL O 24 V DC 24 V DC power output to HVPWB
B17 24VIL O 24 V DC 24 V DC power output to HVPWB
A1 CBACCNT O PWM Developing AC bias control voltage
(Cyan)
A2 MBACCNT O PWM Developing AC bias control voltage
(Magenta)
A3 MCCNT O PWM Chager roller control voltage (Cyan)
A4 HVCLKC O 0/3.3 V DC (pulse) Developing bias clock signal (Cyan)
A5 BCSCNT O PWM Developing sleeve roller bias control volt-
age (Cyan)
A6 BYMCNT O PWM Developing magnet roller bias control
voltage (Yellow)
A7 BCMCNT O PWM Developing magnet roller bias control
voltage (Cyan)
A8 BYSCNT O PWM Developing sleeve roller bias control volt-
age (Yellow)
A9 MYCNT O PWM Chager roller control voltage (Yellow)
A10 YBACCNT O PWM Developing AC bias control voltage (Yel-
low)
A11 HVCLKY O 0/3.3 V DC (pluse) Developing bias clock signal (Yellow)
A12 NC - - Not used
A13 NC - - Not used
A14 NC - - Not used
A15 NC - - Not used
A16 NC - - Not used
A17 NC - - Not used
Connector Pin Signal I/O Voltage Description
Y113010-4 Sevice Manual
To Next Page
