Olivetti d-Color MF2001 User Manual

2KZ/2K0
1-4-38
8830 Bridge communication
error (document finisher)
A communication error is
detected 10 times in succes-
sion.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
Engine PWB (YC19) and DF relay PWB
(YC2)
DF relay PWB (YC4) and bridge PWB (YC5)
Defective bridge
PWB.
Replace the bridge PWB and check for cor-
rect operation.
Defective engine
PWB.
Replace the engine PWB and check for cor-
rect operation (see page 1-5-31).
8900 Backup memory data prob-
lem (document finisher)
Read and write data does not
match 3 times in succession.
Defective connec-
tor cable or poor
contact in the con-
nector.
Check the connection of connector on the
finisher main PWB and the connector of the
machine, and the continuity across the con-
nector terminals. Repair or replace if neces-
sary.
EEPROM installed
incorrectly.
Install EEPROM correctly.
Defective finisher
main PWB.
Replace the finisher main PWB and check
for correct operation.
9000 Document processor com-
munication error
A communication error is
detected 10 times in succes-
sion.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity within the connector cable. If none,
replace the cable.
DP main PWB and engine PWB (YC18)
Defective DP main
PWB.
Replace the DP main PWB and check for
correct operation (see page 1-5-28).
9060 DP EEPROM error
Mismatch between writing
data and reading data occurs
three times successively.
Mismatch of reading data from
two locations occurs three
times successively.
Defective DP main
PWB.
Replace the DP main PWB and check for
correct operation (see page 1-5-28).
Device damage of
EEPROM.
Contact the Service Administrative Division.
9500 BRU communication error IPU PWB error Contact the Service Administrative Division.
9510 BRU PWB error
9520 BRU PWB data error
Code Contents Causes
Check procedures/
corrective measures
Service Manual Y113010-4
