2KZ/2K0
1-3-52
U136
Setting toner near end detection
Description
Sets the level that indicates the number of sheets that can be printed from occurrence of toner
near end to toner empty.
Purpose
To change the setting to advance detection of near end if the interval from toner near end to toner
empty seems too short.
Setting
1. Press the start key.
2. Select the item to be set.
3. Change the setting value using the cursor left/right keys or numeric keys.
Increasing the setting makes the interval from toner near end to toner empty longer.
Decreasing the setting makes the interval from toner near end to toner empty shorter.
If 0 is set, toner near end will not be detected.
4. Press the start key. The value is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U139
Displaying the temperature and humidity outside the machine
Description
Displays the detected temperature and humidity outside the machine.
Purpose
To check the temperature and humidity outside the machine.
Method
1. Press the start key. The detected temperature and humidity are displayed.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description Setting
range
Initial
setting
K Setting the level of black toner 0 to 10 0
CMY Setting the level of cyan/magenta/yellow toner 0 to 10 0
Display Description
External Temperature External temperature (ï‚°C)
External Humidity External humidity ()
Internal Temp1 (LSU) Internal temperature around the laser scanner unit (ï‚°C)
Internal Temp2 Internal temperature around the transfer section (ï‚°C)
Internal Temp3 Internal temperature around the developing section (ï‚°C)
Service Manual Y113010-4
