Olivetti d-Color MF2001 User Manual

2KZ/2K0
1-4-50
(16)
Mid clutch does not
operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Mid clutch and engine PWB (YC2)
2. Defective clutch. Replace the mid clutch.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-31).
(17)
Registration clutch
does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Registration clutch and engine PWB (YC2)
2. Defective clutch. Replace the registration clutch.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-31).
(18)
Duplex clutch does
not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Duplex clutch and engine PWB (YC2)
2. Defective clutch. Replace the duplex clutch.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-31).
(19)
Developer stop
clutch does not
operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Developer stop clutch and engine PWB (YC3)
2. Defective clutch. Replace the developer stop clutch.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-31).
(20)
MP solenoid does
not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
MP solenoid and engine PWB (YC2)
2. Defective solenoid. Replace the MP solenoid.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-31).
(21)
Feedshift solenoid
does not operate.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Feedshift solenoid and engine PWB (YC20)
2. Defective solenoid. Replace the Feedshift solenoid.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-31).
Problem Causes Check procedures/corrective measures
Service Manual Y113010-4
