Olivetti d-Color MF2001 - Checking the Operation of the DP Motors

2KZ/2K0
1-3-62
U243 Checking the operation of the DP motors
Description
Turns the motors or clutches in the DP on.
Purpose
To check the operation of the DP motors and clutches.
Method
1. Press the start key.
2. Select the item to be operated.
3. Press the start key. The operation starts.
4. To turn each motor off, press the stop key.
Completion
Press the stop key when operation stops. The screen for selecting a maintenance item No. is dis-
played.
Item No. Description
Display Description
Conv Motor DP paper feed motor (DPPFM) is turned on
Rev Motor DP switchback motor (DPSBM) is turned on
Feed Clutch DP paper feed clutch (DPPFCL) is turned on
Regist Clutch DP registration clutch (DPRCL) is turned on
Service Manual Y113010-4
