2KZ/2K0
1-3-28
U063 Adjusting the shading position
Description
Changes the shading position of the scanner.
Purpose
Used when the white line continue to appear longitudinally on the image after the shading plate is
cleaned.
This is due to flaws or stains inside the shading plate. To prevent this problem, the shading posi-
tion should be changed so that shading is possible without being affected by the flaws or stains.
Setting
1. Press the start key.
2. Select [Position].
3. Change the setting value using the cursor left/right keys or numeric keys.
Increasing the value moves the shading position toward the machine left, and decreasing it
moves the position toward the machine right.
4. Press the start key. The value is set.
Supplement
While this maintenance item is being executed, copying from an original is available in interrupt
copying mode (which is activated by pressing the system menu key).
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Setting
range
Initial
setting
Change in
value per step
Position Shading position -6 to 18 0 0.091 mm
Service Manual Y113010-4
