2KZ/2K0
1-3-20
U032 Checking the operation of the clutches
Description
Turns each clutch on.
Purpose
To check the operation of each clutch.
Method
1. Press the start key.
2. Select the clutch to be operated.
3. Press the start key. The operation starts.
4. Press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U033 Checking the operation of the solenoids
Description
Turns each solenoid on.
Purpose
To check the operation of each solenoid.
Method
1. Press the start key.
2. Select the solenoid to be operated.
3. Press the start key. The operation starts.
4. Press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Feed Paper feed clutch (PFCL) is turned on
Regist Registration clutch (RCL) is turned on
Duplex Duplex clutch (DUCL) is turned on
Middle Middle clutch (MCL) is turned on
DLP Developer stop clutch (DEVSCL) is turned on
Display Description
MPT MP solenoid (MPSOL) is turned on
Eject Feedshift solenoid (FSSOL) is turned on
Service Manual Y113010-4
