2KZ/2K0
1-3-69
U326 Setting the black line cleaning indication
Description
Sets whether to display the cleaning guidance when detecting the black line.
Purpose
Displays the cleaning guidance in order to make the call for service with the black line decrease
by the rubbish on the contact glass when scanning from the DP.
Method
1. Press the start key.
2. Select the item to set. The screen for setting each item is displayed.
Setting: [Black Line Mode]
1. Select [On] or [Off].
* : Initial setting: On
2. Press the start key. The setting is set.
Setting: [Black Line Cnt]
1. Select [Cnt].
2. Change the setting value using the cursor left/right keys or numeric keys.
* : When setting is 0, the black line cleaning indication is displayed only if the black line is
detected.
3. Press the start key. The value is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Black Line Mode Black line cleaning guidance ON/OFF setting
Black Line Cnt Setting counts of the cleaning guidance indication
Display Description
On Displays the cleaning guidance
Off Not to display the cleaning guidance
Display Description
Setting
range
Initial
setting
Cnt Setting counts of the cleaning guidance
indication ( x 1000 sheets)
0 to 255 8
Y113010-4 Sevice Manual
