Olivetti d-Color MF2001 - A Paper Jam in the Paper Feed; Message Requesting Paper to be Loaded When Paper Present on MP Tray; The Size of Paper on the Cassette Is Not Displayed Correctly; Message Requesting Paper to be Loaded When Paper Present on Cassette

2KZ/2K0
1-4-51
(22)
The message
requesting paper to
be loaded is shown
when paper is
present on the cas-
sette.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Paper sensor and engine connect PWB (YC15)
Engine connect PWB to engine PWB (YC9)
2. Deformed actuator of
the paper sensor.
Check visually and replace if necessary.
3. Defective paper sen-
sor.
Replace the cassette PWB.
4. Defective PWB. Replace the engine PWB or engine connect PWB and
check for correct operation (see page 1-5-31).
(23)
The message
requesting paper to
be loaded is shown
when paper is
present on the MP
tray.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
MP paper sensor and engine PWB (YC28)
2. Deformed actuator of
the MP paper sensor.
Check visually and replace if necessary.
3. Defective MP paper
sensor.
Replace the MP paper sensor.
4. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-31).
(24)
The size of paper
on the cassette is
not displayed cor-
rectly.
1. Defective connector
cable or poor con-
tact in the connector.
Reinsert the connector. Also check for continuity within the
connector cable. If none, replace the cable.
Paper size width switch and engine PWB (YC14)
Paper size length switch and engine PWB (YC14)
2. Defective cassette
size switch.
Replace the paper size width switch or paper size length
switch.
3. Defective PWB. Replace the engine PWB and check for correct operation
(see page 1-5-31).
(25)
A paper jam in the
paper feed, paper
conveying or eject
section is indi-
cated when the
main power switch
is turned on.
1. A piece of paper torn
from paper is caught
around registration
sensor, duplex sen-
sor , feed sensor or
eject sensor.
Check visually and remove it, if any.
2. Defective sensor. Replace the registration sensor, duplex sensor, feed sensor
or eject sensor.
(26)
A message indicat-
ing cover open is
displayed when the
front cover or right
cover is closed.
1. Deformed actuator of
the interlock switch.
Check visually and replace if necessary.
2. Defective interlock
switch.
Replace the interlock switch.
Problem Causes Check procedures/corrective measures
Y113010-4 Sevice Manual
