2KZ/2K0
2-2-3
35. Transfer PWB (TCPWB) ....................... Relays wirings from electrical components on the intermediate
transfer unit.
Intermediate transfer individual information in EEPROM storage.
36. Transfer connect PWB (TCCPWB)....... Consists of wiring relay circuit between engine connect PWB and
Transfer PWB.
37. DP main PWB (DPMPWB) ................... Consists the motor and clutch driver circuit and wiring relay cir-
cuit.
38. DP LED PWB (DPLEDPWB) ................ Displays the presence of the original.
PWB names conversion
No. Name used in service manual Name used in parts list
1 Main PWB (MPWB)
PARTS PWB MAIN ASSY SP
2 Engine PWB (EPWB)
PARTS PWB ENGINE ASSY SP
3 Engine connect PWB (ECPWB)
PARTS PWB ENGINE CONNECT ASSY SP
4 High voltage PWB (HVPWB)
PARTS HVU1 SP
5 High voltage PWB sub (HVPWB-S)
PARTS HVU2 SP
6
Power source PWB (PSPWB)
PARTS LVU MAIN 100 SP
PARTS LVU MAIN 200 SP
7
Power source PWB sub(PSPWB-S)
PARTS LVU SUB 100 SP
PARTS LVU SUB 200 SP
8
IH PWB (IHPWB)
PARTS PWB IH 100 ASSY SP
PARTS PWB IH 200 ASSY SP
9 Operation panel PWB main(OPPWB-M)
PARTS PWB PANEL MAIN ASSY SP
10 Drum connect PWB (DRCPWB)
PARTS PWB DRUM DLP CONNECT ASSY SP
11 Transfer connect PWB (TCCPWB)
PARTS PWB TRANSFER CONNECT ASSY SP
12 LSU connect PWB (LSUCPWB)
PARTS PWB LSU CONNECT ASSY SP
13 RFID PWB (RFIDPWB)
PARTS PWB RFID ASSY SP
14 DP main PWB (DPMPWB) PARTS PWB DRIVE ASSY SP
Y113010-4 Sevice Manual
