2KZ/2K0
2-3-32
Connector Pin Signal I/O Voltage Description
YC1
1 FG - - Ground
Connected to
engine PWB
2 ENG_TMG O 0/3.3 V DC DPTS: On/Off
3 ENG_RDY O 0/3.3 V DC Ready signal
4 ENG_SEL I 0/3.3 V DC Select signal
5 ENG_CLK I 0/3.3 V DC(pulse) Clock signal
6 ENG_SI I 0/3.3 V DC(pulse) Serial communication data signal
7 ENG_SO O 0/3.3 V DC(pulse) Serial communication data signal
8 ENG_OPEN O 0/3.3 V DC DPOCS: On/Off
9 NC - - Not used
10 GND - - Ground
11 GND - - Ground
12 GND - - Ground
13 NC - - Not used
14 +24V O 24 V DC 24 V DC power input from EPWB
15 +24V O 24 V DC 24 V DC power input from EPWB
16 +24V O 24 V DC 24 V DC power input from EPWB
YC2
1 ANODE O 3.3 V DC 3.3 V DC power output to DPOLS
Connected to
DP original
size length
sensor
2 GND - - Ground
3 LS_SW I 0/3.3 V DC DPOLS: On/Off
YC3
1 ANODE O 3.3 V DC 3.3 V DC power output to DPOS
Connected to
DP original
sensor
2 GND - - Ground
3 SET_SW I 0/3.3 V DC DPOS: On/Off
YC4
1 WID1 I 0/3.3 V DC DPOWS: On/Off
Connected to
DP original
size width
sensor
2 GND - - Ground
3 WID2 I 0/3.3 V DC DPOWS: On/Off
4 WID3 I 0/3.3 V DC DPOWS: On/Off
Service Manual Y113010-4
