2KZ/2K0
1-4-12
1020 PF lift motor 1 error
(paper feeder)
After cassette 2 is inserted,
PF lift sensor 1 does not turn
on within 12 s. This error is
detected four times succes-
sively.
Defective bottom
plate elevation
mechanism in the
cassette.
Check to see if the bottom plate can move
smoothly and repair any problem that is
found.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity of the connector cable. If necessary,
replace the cable.
PF lift motor 1 and PF main PWB (YC4)
Defective drive
transmission sys-
tem of the PF lift
motor 1.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if necessary.
Defective PF lift
motor 1.
Replace the PF lift motor 1.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual of the paper feeder).
1030 PF lift motor 2 error
(paper feeder)
After cassette 3 is inserted,
PF lift sensor 2 does not turn
on within 12 s. This error is
detected four times succes-
sively.
Defective bottom
plate elevation
mechanism in the
cassette.
Check to see if the bottom plate can move
smoothly and repair it if any problem is
found.
Defective connec-
tor cable or poor
contact in the con-
nector.
Reinsert the connector. Also check for conti-
nuity of the connector cable. If necessary,
replace the cable.
PF lift motor 2 and PF main PWB (YC7)
Defective drive
transmission sys-
tem of the PF lift
motor 2.
Check if the gears rotate smoothly. If not,
grease the bushes and gears. Check for
broken gears and replace if any.
Defective PF lift
motor 2.
Replace the PF lift motor 2.
Defective PF main
PWB.
Replace the PF main PWB (Refer to the ser-
vice manual of the paper feeder).
Code Contents Causes
Check procedures/
corrective measures
Service Manual Y113010-4
