2KZ/2K0
1-3-49
U111 Checking the drum drive time
Description
Displays the drum drive time for checking a figure, which is used as a reference when correcting
the high voltage based on time.
Purpose
To check the drum status.
Method
1. Press the start key.
2. Select the item. The drum drive time is displayed.
Setting
1. Change the drum drive time using the cursor left/right keys or numeric keys.
2. Press the start key. The drum drive time is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
C
Cyan drum drive time
M
Magenta drum drive time
Y
Yellow drum drive time
K
Black drum drive time
Y113010-4 Sevice Manual
