2KZ/2K0
1-3-16
U019 Displaying the ROM version
Description
Displays the part number of the ROM fitted to each PWB.
Purpose
To check the part number or to decide, if the newest version of ROM is installed.
Method
1. Press the start key. The ROM version are displayed.
2. Change the screen using the cursor up/down keys.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Main Main ROM
MMI Operation ROM
Engine Engine ROM
Engine Boot Engine booting
RFID RFID ROM
IO CPU IO CPU ROM
IO CPU Boot IO CPU booting
Option Language Optional language ROM
Dictionary -
DP Document processor ROM
DP Boot Document processor booting
PF Paper feeder ROM
PF Boot Paper feeder booting
DF Document finisher ROM
DF Boot Document finisher booting
AK Bridge ROM
AK Boot Bridge booting
Fax APL Fax control PWB APL
Fax Boot Fax control PWB booting
Fax IPL Fax control PWB IPL
Service Manual Y113010-4
