2KZ/2K0
1-3-45
U106 Setting the voltage for the secondary transfer
Description
Sets the control voltage for the secondary transfer.
Purpose
To change the setting when any density problems, such as too dark or light, occur.
Method
1. Press the start key.
2. Select the item. The screen for executing each item is displayed.
Method:[Color]
1. Select the item. The screen for executing each item is displayed.
Method: [Light/Normal1 / Normal2/3 / Heavy1 / Heavy2-3]
1. Select the item. The screen for executing each item is displayed.
Setting:[1st side/2nd side]
1. Select the item to be set.
2. Change the setting value using the cursor left/right keys or numeric keys.
3. Press the start key. The value is set.
Item No. Description
Display Description
Color Correction value of color printing
B/W Correction value of monochrome printing
Display Description
Light/Normal1
Weight of paper (light to usual 1)
Normal2/3
Weight of paper (usual 2 to 3)
Heavy1
Weight of paper (heavy 1)
Heavy2-3
Weight of paper (heavy 2 to 3)
OHP
Kind of paper (OHP)
Coated
Kind of paper (Coated paper)
Display Description
1st side
Correction value of single-side printing
2nd side
Correction value of duplex printing
Display Description
Setting
range
Initial
setting
Width<160 width of paper<160
0 to 200 60/60/45/40
80/82/55/40
160<=Width<220 160<= width of paper <220
0 to 200 53/55/41/35
47/52/39/32
220<=Width 220<= width of paper
0 to 200 45/48/38/30
43/45/35/27
Y113010-4 Sevice Manual
