2KZ/2K0
1-3-46
U106 Setting:[OHP/Coated]
1. Select the item to be set.
2. Change the setting value using the cursor left/right keys or numeric keys.
3. Press the start key. The value is set.
Method:[B/W]
1. Select the item. The screen for executing each item is displayed.
Method: [Light/Normal1 / Heavy1 / Heavy2-3]
1. Select the item. The screen for executing each item is displayed.
Setting:[1st side/2nd side]
1. Select the item to be set.
2. Change the setting value using the cursor left/right keys or numeric keys.
3. Press the start key. The value is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Setting
range
Initial
setting
Width<160 width of paper<160
0 to 200 35/45
160<=Width<220 160<= width of paper <220
0 to 200 35/35
220<=Width 220<= width of paper
0 to 200 25/30
Display Description
Light/Normal1
Weight of paper (light to usual 1)
Heavy1
Weight of paper (heavy 1)
Heavy2-3
Weight of paper (heavy 2 to 3)
Display Description
1st side
Correction value of single-side printing
2nd side
Correction value of duplex printing
Display Description
Setting
range
Initial
setting
Width<160 width of paper<160
0 to 200 55/45/40
65/55/38
160<=Width<220 160<= width of paper <220
0 to 200 50/41/32
50/40/30
220<=Width 220<= width of paper
0 to 200 40/38/27
3736/25
Service Manual Y113010-4
To Next Page
