2KZ/2K0
1-3-54
U140 Setting: [On Timing/On Timing]
1. Select the item to be set.
2. Change the setting value using the cursor left/right keys or numeric keys.
3. Press the start key. The value is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
U147 Setting for toner applying operation
Description
Sets the mode for removing charged toner in the developer unit (T7 control: Toner applying oper-
ation).
Purpose
Changing settings are not required. However, when the documents with lower print density (e.g.
less than 2%) should customarily printed in a great volume, mode must be changed.
If the charged toner stays inside the developer unit, density decreases.
Setting
1. Press the start key
2. Select the item to be set.
3. Change the setting value using the cursor left/right keys or numeric keys.
4. Press the start key. The setting is set.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
Setting
range
Initial
setting
1st Setting the value of yellowt.
-500 to 500 0/0
2nd Setting the value of cyan.
-500 to 500 0/0
3rd Setting the value of magenta.
-500 to 500 0/0
4th Setting the value of black.
-500 to 500 0/0
Display Description Setting range
Initial
setting
T7 T7 Operational mode 0 to 1 0
Drum T7 Drum T7 operational mode 0 to 255 60
Service Manual Y113010-4
