2KZ/2K0
1-3-43
U101 Setting the voltage for the primary transfer
Description
Sets the control voltage for the primary transfer.
Purpose
To change the setting when any density problems, such as too dark or light, occur.
Method
1. Press the start key.
2. Select the item. The screen for executing each item is displayed.
Setting: [Base]
1. Select the item to be set.
2. Change the setting value using the cursor left/right keys or numeric keys.
3. Press the start key. The value is set.
Setting: [1st side/02nd side]
1. Select the item to be set.
2. Change the setting value using the cursor left/right keys or numeric keys.
3. Press the start key. The value is set.
Item No. Description
Display Description
Base Standard value
1st side Correction value of single-side printing
2nd side Correction value of duplex printing
B/W Correction value of monochrome printing
Display Description
Setting
range
Initial
setting
Full Full speed printing 0 to 100
55
Half Half speed printing 0 to 100
35
Display Description
Setting
range
Initial
setting
1st Correction value (Yellow) -50 to 50
0/-3
2nd Correction value (Cyan) -50 to 50
15/-3
3rd Correction value (Magenta) -50 to 50
5/-3
4th Correction value (Black) -50 to 50
20/-3
Y113010-4 Sevice Manual
