Olivetti d-Color MF2001 - Setting the Adjustment of the Motor Speed

2KZ/2K0
1-3-26
U053 Setting the adjustment of the motor speed
Description
Performs fine adjustment of the speeds of the motors.
Purpose
To adjust the speed of the respective motors when the magnification is not correct.
Method
1. Press the start key.
2. Select the item to be adjusted.
Item No. Description
Display Description
Setting
range
Initial
setting
Feed
Conveying motor (CM) speed adjust-
ment
-50 to 50 -
Exit Eject motor (EM) speed adjustment -40 to 40 0
Drum(CMY)
Drum motor (DRM-YCM) speed adjust-
ment
-50 to 50 5
Drum(K)
Drum motor (DRM-K) speed adjust-
ment
-50 to 50 5
DLP(CMY)
DLP motor (DEVM-YCM) speed adjust-
ment
-50 to 50 0
DLP(K)
DLP motor (DEVM-K) speed adjust-
ment
-50 to 50 5
Fixing
Fixing motor(FUM) speed adjustment -50 to 50 10
Porygon(CMY)
Porygon motor(PM-YCM) speed
adjustment
-20 to 20 0
Porygon(K)
Porygon motor (PM-K) speed adjust-
ment
-20 to 20 0
Service Manual Y113010-4
