2KZ/2K0
1-3-55
U150 Checking sensors for toner
Description
Displays the on-off status of each sensor or switch related to toner.
Purpose
To check if the sensors and switches operate correctly.
Method
1. Press the start key.
2. Select the item. The screen for executing each item is displayed.
Method: [T/C]
1. Turn each switch or sensor on and off manually to check the status.
When a switch or sensor is detected to be in the ON position, the display for that switch or
sensor will be “1”
2. To stop motor driving, press the stop key.
Method: [Waste Box]
1. Turn each switch or sensor on and off manually to check the status.
When a switch or sensor is detected to be in the ON position, the display for that switch or
sensor will be “1”
2. To stop motor driving, press the stop key.
Completion
Press the stop key. The screen for selecting a maintenance item No. is displayed.
Item No. Description
Display Description
T/C
Displays the state of the toner sensor.
Waste Box
Displays the state of the waste toner box.
Display Switches and sensors
T/C Sensor 1st
Displays the state of the toner sensor (Yellow).
T/C Sensor 2nd
Displays the state of the toner sensor (Cyan).
T/C Sensor 3rd
Displays the state of the toner sensor (Magenta).
T/C Sensor 4th
Displays the state of the toner sensor (Black).
Motor
Drives developer motor, developer clutch.
Display Switches and sensors
Waste Box Sensor
Displays the state of the waste toner box.
Motor
Drives developer motor, developer clutch.
Y113010-4 Sevice Manual
