2KZ/2K0
1-3-53
U140 Setting developer bias
Description
Setting the value of various developer bias.
Purpose
To check and setting the value of developer bias.
Method
1. Press the start key.
2. Select the item to be set or displayed.
Setting: [Mag DC/Sleeve DC/Clock Freq/Clock Duty/AC Ctrl]
1. Select the item to be set.
2. Change the setting value using the cursor left/right keys or numeric keys.
3. Press the start key. The value is set.
Item No. Description
Display Description
Mag DC
Setting the value of magnet DC bias.
Sleeve DC
Setting the value of sleeve DC bias.
Clock Freq
Setting the value of clock frequency.
Clock Duty
Setting the value of clock duty.
AC Ctrl
Setting the value of AC control voltage.
On Timing
Setting the value of developer On timing.
Off Timing
Setting the value of developer Off timing.
Display Description
Initial
setting
1st Setting the value of yellow.
450/150/36/27/1400
2nd Setting the value of cyan.
480/180/36/27/1400
3rd Setting the value of magenta.
480/180/36/27/1400
4th Setting the value of black.
450/150/36/27/1400
Remove 1st
Setting the value of remove yellow. 50/150/36/27/1000
Remove 2nd
Setting the value of remove cyan. 50/150/36/27/1000
Remove 3rd
Setting the value of remove magenta. 50/150/36/27/1000
Remove 4th
Setting the value of remove black. 50/150/36/27/1000
Remove 1st Half
Setting the value of remove yellow Half. 350/180/36/27/1200
Remove 2nd Half
Setting the value of remove cyan Half. 350/180/36/27/1200
Remove 3rd Half
Setting the value of remove magenta Half. 350/180/36/27/1200
Remove 4th Half
Setting the value of remove black Half. 350/180/36/27/1200
Y113010-4 Sevice Manual
