Olivetti d-Color MF2001 User Manual

2KZ/2K0
2-3-9
YC3
1 DLPC_MT_DI
R
O 0/5V DC DEVM-YCM drive shift signal
Connected to
developer
motor YCM,
developer
stop clutch,
drum motor
YCM, drum
motor K
2 DLPC_MT_R
DY
I 0/3.3 V DC DEVM-YCM ready signal
3 DLPC_MT_CL
K
O 0/5 V DC (pulse) DEVM-YCM clock signal
4 DLPC_MT_R
EM
O 0/5 V DC DEVM-YCM: On/Off
5 GND - - GROUND
6 24V4 O 24 V DC 24 V DC power output to DEVM-YCM
7 24V4 O 24 V DC 24 V DC power output to DEVSCL
8 DLP_CL_REM O 0/3.3 V DC DEVSCL: On/Off
9 DRMC_MT_DI
R
O 0/5 V DC DRM-YCM drive shift signal
10 DRMC_MT_R
DY
I 0/3.3 V DC DRM-YCM ready signal
11 DRMC_MT_C
LK
O 0/5 V DC (pulse) DRM-YCM clock signal
12 DRMC_MT_R
EM
O 0/5 V DC DRM-YCM: On/Off
13 GND - - GROUND
14 24VIL O 24 V DC 24 V DC power output to DRM-YCM
15 DRMK_MT_DI
R
O 0/5 V DC DRM-K drive shift signal
16 DRMK_MT_R
DY
I 0/3.3 V DC DRM-K ready signal
17 DRMK_MT_C
LK
O 0/5 V DC (pulse) DRM-K clock signal
18 DRMK_MT_R
EM
O 0/5 V DC DRM-K: On/Off
19 GND - - GROUND
20 24VIL O 24 V DC 24 V DC power output to DRM-K
Connector Pin Signal I/O Voltage Description
Y113010-4 Sevice Manual
