Olivetti d-Color MF2001 - Repetitive Defects Gauge

2KZ/2K0
2-4-2
(2) Repetitive defects gauge
First occurrence of defect
50.3 mm/2” Developing roller
37.7 mm/1
1/2” Chager roller
94.2 mm/3
11/16” Drum/Press roller
46.5 mm/1
13/16” Left registration roller
125.7 mm/4
15/16” Heat roller
62.0 mm/2 7/16” Right registration roller
65.7 mm/2 9/16” Transfer roller
Service Manual Y113010-4
