2KZ/2K0
1-3-42
U100 Setting the main high voltage
Description
Performs main charging.
Purpose
To check main charging.
Setting: [IDC Bias]
1. Select an item to be set.
2. Change the setting value using the cursor left/right keys or numeric keys.l
3. Press the start key. The value is set.
Completion
Press the stop key when main charger output stops. The screen for selecting a maintenance item
No. is displayed.
Item No. Description
Display Description
Setting
range
Initial
setting
1st Set value of the MC DC bias (Yellow) 0 to 250
145
2nd Set value of the MC DC bias (Cyan) 0 to 250
145
3rd Set value of the MC DC bias (Magenta) 0 to 250
145
4th Set value of the MC DC bias (Black) 0 to 250
145
Service Manual Y113010-4
