Omron DRT2 SERIES DEVICENET SLAVES - OPERATION MANUAL 04-2008 User Manual

180
Connector Terminals with Transistors Section 5-6
Mounted Perpendicular to a Panel
Mounted Parallel to a Panel
Mounting Bracket
Dimensions
The dimensions of the SRT2-ATT02 Mounting Bracket B are shown below.
Wiring Internal Power
Supplies, I/O Power
Supplies and I/O
Internal power is supplied together with the communications power supply
and does not need to be wired separately. I/O power supplies and I/O are
wired through the I/O MIL connector.
35 mm45 mm
3.3 mm
Mounting Bracket B
0.1 mm
35 mm45 mm
Mounting Bracket B
32.5
35
7.3
Two, 3.2 dia. or M3
Mounting holes
16±0.2
