Connector Terminals with Transistors Section 5-6
The MIL pin numbers, loose wire colors, dot markings, and dot colors are
listed in the following table.
Using Pressure-welded Flat Cable Connectors
Use the following procedure to prepare flat cables with XG4M-4030-T MIL
Connectors.
1,2,3... 1. Use precision screwdrivers to open the hooks on both ends and separate
the contacts from the cover of the MIL socket. There are two tabs on each
end of the contact side of the socket. Release both of these at the same
time, not one at a time.
2. Place the flat cable between the contacts and cover of the socket, align the
contacts, and press on the cover to lock it in place on the contacts. Use a
vise or similar device to firmly press the cover on until the tabs are properly
joined.
Applicable Wires: 1.27-mm pitch flat cable, AWG28 (7-strand wire)
Pin
No.
Core
color
Dot
marking
Dot color Pin
No.
Core
color
Dot
marking
Dot color
1Light
brown
â– Black 21 Light
brown
â– â– â– Black
2Red22Red
3 Yellow Black 23 Yellow Black
4Red24Red
5Light
green
Black 25 Light
green
Black
6Red26Red
7 Gray Black 27 Gray Black
8Red28Red
9 White Black 29 White Black
10 Red 30 Red
11 Light
brown
â– â– Black 31 Light
brown
â– â– â– â– Black
12 Red 32 Red
13 Yellow Black 33 Yellow Black
14 Red 34 Red
15 Light
green
Black 35 Light
green
Black
16 Red 36 Red
17 Gray Black 37 Gray Black
18 Red 38 Red
19 White Black 39 White Black
20 Red 40 Red
