Chapter 10: Technical Specifications
Callout Description mm
L Distance between the rear casters pivot
points
600
NOTE: Refer also to Figure 5-1. for mounting hole dimensions for the payload
structure.
31500-000 Rev A HD-1500 Platform User's Manual 272
