5
-
3
5
n Motor 2 V/f Pattern: E3
Parameters for motor 2 V/f characteristics are shown in the following table.
Param-
eter
Num-
ber
Name
Description
Setting
Range
Factory
Setting
Change
during
Opera-
tion
Control Methods
Register
Page
LCD
Display
V/f
V/f
with
PG
Open
Loop
E3-01
Motor 2
control
method
selection
0:V/f control
1:V/f control with PG
2: Open-loop vector control
0 to 2 0 No A A A 319H -
Control
Method
E3-02
Motor 2
max. out-
put fre-
quency
(FMAX)
To set V/f characteristics in a
straight line, set the same values
for E3-05 and E3-07.
In this case, the setting for E3-06
will be disregarded.
Always ensure that the four fre-
quencies are set in the following
manner:
E3-02 (FMAX) ≥ E3-04 (FA) >
E3-05 (FB) > E3-07 (FMIN)
40.0 to
400.0
*3
60.0
Hz
(50.0
Hz)
*4
No A A A 31AH -
Max Fre-
quency
E3-03
Motor 2
max. volt-
age
(VMAX)
0.0 to
255.0
*1
200.0
V
*2
No A A A 31BH -
Max Volt-
age
E3-04
Motor 2
max. volt-
age fre-
quency
(FA)
0.0 to
400.0
60.0
Hz
(50.0
Hz)
*4
No A A A 31CH -
Base Fre-
quency
E3-05
Motor 2
mid. out-
put fre-
quency 1
(FB)
0.0 to
400.0
3.0 Hz
*2
No A A A 31DH -
Mid Fre-
quency
E3-06
Motor 2
mid. out-
put fre-
quency
voltage 1
(VC)
0.0 to
255.0
*1
15.0 V
*1
No A A A 31EH -
Mid Vol t-
age
E3-07
Motor 2
min. out-
put fre-
quency
(FMIN)
0.0 to
400.0
1.5 Hz
*2
No A A A 31FH -
Min Fre-
quency
Output voltage (V)
Frequency (Hz)
