Omron SYSDRIVE 3G3RV Series

P
arameters
1
0
-
1
5
10
C4-02
Torque compensation primary
delay time constant
200
*2
d6-01 Field weakening level 80
C4-03 Starting torque value (forward) 0.0 d6-02 Field frequency 0.0
C4-04 Starting torque value (reverse) 0.0 E1-01 Input voltage setting
200
*7
C4-05 Starting torque time constant 10 E1-03 V/f pattern selection F
C5-01 ASR proportional (P) gain 1 0.20 E1-04 Max. output frequency 60.0
C5-02 ASR integral (I) time 1 0.200 E1-05 Max. voltage
200.0
*2 *7
C5-03 ASR proportional (P) gain 2 0.02 E1-06 Base frequency
60.0
*2
C5-04 ASR integral (I) time 2 0.050 E1-07 Mid. output frequency
3.0
*2
C5-05 ASR limit 5.0 E1-08 Mid. output frequency voltage
15.0
*2 *7
C6-01 CT/VT selection 1 E1-09 Min. output frequency
1.5
*2
C6-02 Carrier frequency selection
6
*6
E1-10 Min. output frequency voltage
9.0
*2 *7
C6-03 Carrier Frequency Upper Limit
15.0
*6
E1-11 Mid. output frequency 2
0.0
*9
C6-04 Carrier Frequency Lower Limit
15.0
*6
E1-12 Mid. output frequency voltage 2
0.0
*9
C6-05
Carrier Frequency Proportional
Gain
00 E1-13 Base voltage
0.0
*10
d1-01 Frequency reference 1 0.00 E2-01 Motor rated current
1.90
*6
d1-02 Frequency reference 2 0.00 E2-02 Motor rated slip
2.90
*6
d1-03 Frequency reference 3 0.00 E2-03 Motor no-load current
1.20
*6
d1-04 Frequency reference 4 0.00 E2-04 Number of motor poles 4
d1-05 Frequency reference 5 0.00 E2-05 Motor line-to-line resistance
9.842
*6
d1-06 Frequency reference 6 0.00 E2-06 Motor leak inductance
18.2
*6
d1-07 Frequency reference 7 0.00 E2-07 Motor iron saturation coefficient 10.50
d1-08 Frequency reference 8 0.00 E2-08 Motor iron saturation coefficient 20.75
d1-09 Frequency reference 9 0.00 E2-10
Motor iron loss for torque compen-
sation
14
*4
d1-10 Frequency reference 10 0.00 E2-11 Motor rated output
0.40
*4
d1-11 Frequency reference 11 0.00 E3-01 Motor 2 control method selection 0
d1-12 Frequency reference 12 0.00 E3-02
Motor 2 max. output frequency
(FMAX)
60.0
*2
d1-13 Frequency reference 13 0.00 E3-03 Motor 2 max. voltage (VMAX)
200.0
*2
d1-14 Frequency reference 14 0.00 E3-04
Motor 2 max. voltage frequency
(FA)
60.0
d1-15 Frequency reference 15 0.00 E3-05
Motor 2 mid. output frequency 1
(FB)
3.0
*2
d1-16 Frequency reference 16 0.00 E3-06
Motor 2 mid. output frequency
voltage 1 (VC)
15.0
*7
d1-17 Jog frequency reference 6.00 E3-07
Motor 2 min. output frequency
(FMIN)
1.5
*2
d2-01 Frequency reference upper limit 100.0 E3-08
Motor 2 min. output frequency
voltage (VMIN)
9.0
*7
d2-02 Frequency reference lower limit 0.0 E4-01 Motor 2 rated current
1.90
*6
d2-03 Master speed reference lower limit 0.0 E4-02 Motor 2 rated slip
2.90
*6
d3-01 Jump frequency 10.0E4-03Motor 2 no-load current
1.20
*6
d3-02 Jump frequency 20.0E4-04
Motor 2 number of poles (number
of poles)
4
d3-03 Jump frequency 30.0E4-05Motor 2 line-to-line resistance
9.842
*6
d3-04 Jump frequency width 1.0 E4-06 Motor 2 leak inductance
18.2
*6
d4-01
Frequency reference hold function
selection
0 E4-07 Motor 2 rated capacity
0.40
*6
d4-02 + - Speed limits 10 F1-01 PG constant 600
Table 10.1 Parameters (Continued)
No. Name
Fac-
tory
Setting
Set-
ting
No. Name
Fac-
tory
Setting
Set-
ting
