Omron SYSDRIVE 3G3RV Series

P
arameters
1
0
-
1
7
10
L1-01 Motor protection selection 1 L7-03 Forward regenerative torque limit 200
L1-02 Motor protection time constant 1.0 L7-04 Reverse regenerative torque limit 200
L1-03
Alarm operation selection during
motor overheating
3 L8-01
Protect selection for internal DB
resistor
0
L1-04
Motor overheating operation selec-
tion
1 L8-02 Overheat pre-alarm level 95
L1-05
Motor temperature input filter time
constant
0.20 L8-03
Operation selection after overheat
pre-alarm
3
L2-01 Momentary power loss detection 0 L8-05
Input open-phase protection selec-
tion
0
L2-02
Momentary power loss ridethru
time
0.1
*6
L8-07
Output open-phase protection
selection
0
L2-03 Min. baseblock time 0.1 L8-09 Ground protection selection 1
L2-04 Voltage recovery time 0.3 L8-10 Cooling fan control selection 0
L2-05 Undervoltage detection level
190
*7
L8-11 Cooling fan control delay time 60
L2-06 KEB deceleration time 0.0 L8-12 Ambient temperature 45
L2-07 Momentary recovery time
0
*11
L8-15
OL2 characteristics selection at
low speeds
1
L2-08
Frequency reduction gain at KEB
start
100 L8-18 Soft CLA selection 1
L3-01
Stall prevention selection during
accel
1N1-01
Hunting-prevention function selec-
tion
1
L3-02 Stall prevention level during accel 120 N1-02 Hunting-prevention gain 1.00
L3-03 Stall prevention limit during accel 50 N2-01
Speed feedback detection control
(AFR) gain
1.00
L3-04
Stall prevention selection during
decel
1N2-02
Speed feedback detection control
(AFR) time constant
50
L3-05
Stall prevention selection during
running
1N2-03
Speed feedback detection control
(AFR) time constant 2
750
L3-06
Stall prevention level during run-
ning
120 N3-01
High-slip braking deceleration fre-
quency width
5
L4-01 Speed agreement detection level 0.0 N3-02 High-slip braking current limit 150
L4-02 Speed agreement detection width 2.0 N3-03 High-slip braking stop dwell time 1.0
L4-03
Speed agreement detection level
(+/-)
0.0 N3-04 High-slip braking OL time 40
L4-04
Speed agreement detection width
(+/-)
2.0 o1-01 Monitor selection 6
L4-05
Operation when frequency refer-
ence is lost
0 o1-02 Monitor selection after powerup 1
L4-06
Frequency reference for loss of fre-
quency reference
80.0 o1-03
Frequency units of reference set-
ting and monitor
0
L5-01 Number of auto restart attempts 0 o1-05 LCD brightness 3
L5-02 Auto restart operation selection 0 o2-01
LOCAL/REMOTE key enable/dis-
able
1
L6-01 Torque detection selection 1 0 o2-02
STOP key during control circuit
terminal operation
1
L6-02 Torque detection level 1 150 o2-03 Parameter initial value 0
L6-03 Torque detection time 1 0.1 o2-04 kVA selection
0
*6
L6-04 Torque detection selection 2 0 o2-05
Frequency reference setting
method selection
0
L6-05 Torque detection level 2 150 o2-06
Operation selection when digital
operator is disconnected
0
L6-06 Torque detection time 2 0.1 o2-07 Cumulative operation time setting 0
L7-01 Forward drive torque limit 200 o2-08
Cumulative operation time selec-
tion
0
L7-02 Reverse drive torque limit 200 o2-09 Factory use -
Table 10.1 Parameters (Continued)
No. Name
Fac-
tory
Setting
Set-
ting
No. Name
Fac-
tory
Setting
Set-
ting
