Omron SYSDRIVE 3G3RV Series

1
0
-
18
*1.Not initialized. (Japanese standard specifications: A1-01 = 1, A1-02 = 2)
*2.The factory setting will change if the control method is changed. The factory settings given above are for V/f with PG control.
* 3. Factory setting depends on the control method (A1-02).
*4.For V/f with PG control: 1.0
*5.For Inverters with a capacity of 55 kW or more: 2.00
* 6. Setting range and initial setting depend on Inverter capacity.
* 7. Setting for 200-V class Inverters. For 400-V class Inverters, double the value.
* 8. Factory setting in the parentheses is for 3-wire sequence.
*9.The contents is ignored if the setting is 0.0.
* 10.E1-13 will have the same value as E1-05 after autotuning.
* 11.If the set value is 0, acceleration will be to the speeds for the acceleration times (C1-01 to C1-08)
* 12.The setting range is 10% to 200% of the Inverter rated output. (The value given is for a 200-V class Inverter for 0.4 kW.)
o2-10 Fan operation time setting 0 T1-02 Motor output power 0.40
o2-12
Fault trace/fault history initializa-
tion
0 T1-03 Motor rated voltage
200.0
*7
o3-01 Copy function selection 0 T1-04 Motor rated current
1.90
*6
o3-02 Read permitted selection 0 T1-05 Motor base frequency 60.00
T1-00 Motor 1/2 selection 1 T1-06 Number of motor poles 4
T1-01 Autotuning mode selection 0 T1-07 Motor base speed 1750
Table 10.1 Parameters (Continued)
No. Name
Fac-
tory
Setting
Set-
ting
No. Name
Fac-
tory
Setting
Set-
ting
