Omron SYSMAC CV Series - Page 491

480
Instruction
OFF execution time (µs)ON execution time (µs)
ConditionsWords
CV1000*CV500*CV1000*CV500*
SRCH(164) 5 When searching 1 word 347 289 1.35 1.13
When searching 1000 words for *DM
11.4 ms 9.54 ms
MAX(165) 5 When searching 1 word 464 386 1.35 1.13
When searching 1000 words for *DM
68.2 ms 56.9 ms
MIN(166) 5 When searching 1 word 465 388
When searching 1000 words for *DM
68.2 ms 57.1 ms
SUM(167) 5 When adding 1 word 758 632
When adding 1000 words via *DM
173 ms 144 ms
TRSM(170) 2 When sampling 1 point + 0 word 21.6 18.0
When sampling 12 points + 3 words 50.4 42.0
EMBC(171) 3 When setting a constant 3.6 3.0 1.05 0.88
When setting *DM
5.4 4.5
CCL(172) 2 --- 2.6 2.1 0.9 0.75
CCS(173) 2 --- 2.0 1.6
MARK(174) 3 When sampling 0 words 17.7 14.8 2.7 2.25
When sampling 2 words 24.8 20.6
REGL(175) 3 When setting a word 5.9 4.9 1.05 0.88
When setting *DM
7.1 5.9
REGS(176) 3 When setting a word 9.8 8.1
When setting *DM
11.0 9.1
FPD(177) 5
Without message output: execution 930 775
263 219
()
Without message output: first time 971 809
With message output: execution 1.00 ms 835
With message output: first time 1.05 ms 874
WDT(178) 3 --- 8.61 7.18
1.05 0.88
DATE(179) 3
Word designation 310 259
()
*DM designation 315 262
FILR(180) 5 --- 415 406 1.35 1.13
FILW(181) 5 --- 423 414
FILP(182) 5 When reading 10 steps 99.2 ms 99.2 ms 1.05 0.88
When reading 1000 steps 519 ms 519 ms
FLSP(183) 4 --- 29.4 ms 29.4 ms 1.2 1.0
IORF(184) 4 When refreshing 1 word 27.6 23.6 1.2 1.0
When refreshing 32 words 325 279
IOSP(187) 2 --- 230 228 0.9 0.75
IORS(188) 2 --- 2.4 2.0 IL: 0.9 IL: 0.75
IODP(189) 4 --- 369 308 1.2 1.0
READ(190) 5 When reading 1 word 568 473 1.35 1.13
When reading 255 words 4.64 ms 3.87 ms
WRIT(191) 5 When writing 1 word 661 551
When writing 255 words 4.9 ms 4.1 ms
SEND(192) 5 --- 244 235
RECV(193) 5 --- 251 241
CMND(194) 5 --- 240 230
MSG(195) 4 When specifying constant and a word 6.2 5.1 1.2 1.0
When specifying two *DM
9.2 7.6
TOUT(202) 2 --- 4.7 3.9 4.7 3.9
*Note: CV500 = CV500 or CVM1-CPU01-EV2; CV1000 = CV1000, CV2000, or CVM1-CPU11/21-EV2
Instruction Execution Times Section 6-4
