481
Instruction
OFF execution time (µs)ON execution time (µs)
ConditionsWords
CV1000*CV500*CV1000*CV500*
SA(210) 4 When activating 1 step 39.5 32.9 1.2 1.0
When activating a 15-step subchart 48.2 40.1
SP(211) 3 When pausing 1 step 25.8 21.5 1.05 0.88
When pausing a 15-step subchart 64.8 54.0
SR(212) 3 When releasing 1 step 26.4 22.0
When releasing a 15-step subchart 65.4 54.5
SF(213) 3 When stopping 1 step 25.7 21.4
When stopping a 15-step subchart 62.4 52.0
SE(214) 3 When inactivating 1 step 609 507
When inactivating a 15-step subchart 810 675
SOFF(215) 3 When resetting 1 step 621 518
When resetting a 15-step subchart 2.2 ms 1.9 ms
CJP(221) 3 Jumping to designated word 10.5 8.75 2.85 2.38
Jumping to designated *DM
11.9 9.88
CJPN(222) 3 Jumping to designated word 10.5 8.75 2.70 2.25
Jumping to designated *DM
11.9 9.88
CNR(236) 4 When resetting 1 word 20.3 16.9 1.2 1.0
When resetting 1000 words via *DM
623 519
BPRG(250) 3 --- 5.85 4.88 3.00 2.50
RLNC(260) 3 Rotating word 11.6 9.63 1.05 0.88
Rotating *DM
14.1 11.8
RRNC(261) 3 Rotating word 11.7 9.75
Rotating *DM
14.3 11.9
RLNL(262) 3 Rotating word 12.9 10.8
Rotating *DM
15.5 12.9
RLNL(263) 3 Rotating word 12.9 10.8
Rotating *DM
15.5 12.9
PID(270) 5 When not sampling 22.7 18.9 5.40 4.50
When sampling 368 306
When executing first time 807 673
LMT(271) 5 Input, output word designation 17.3 14.3 1.35 1.13
Input, output *DM designation
25.1 20.9
BAND(272) 5 Input, output word designation 17.3 14.4
Input, output *DM designation
25.2 21.0
ZONE(273) 5 Input, output word designation 17.6 14.6
Input, output *DM designation
25.5 21.3
ROTB(274) 3 Word → word 41.6 34.6 1.20 1.00
*DM → *DM
46.8 39.0
BINS(275) 5 Word → word 16.1 13.4 1.35 1.13
*DM → *DM
25.1 20.9
BCDS(276) 5 Word → word 16.2 13.5
*DM → *DM
24.3 20.3
BISL(277) 5 Word → word 21.3 17.8
*DM → *DM
30.5 25.4
BDSL(278) 5 Word → word 23.3 19.4
*DM → *DM
31.4 26.1
RD2(280) 5 Reading 1 word to word 20.3 16.9 5.25 4.38
*Note: CV500 = CV500 or CVM1-CPU01-EV2; CV1000 = CV1000, CV2000, or CVM1-CPU11/21-EV2
Instruction Execution Times Section 6-4
