Omron SYSMAC CV Series - Page 493

482
Instruction
OFF execution time (µs)ON execution time (µs)
ConditionsWords
CV1000*CV500*CV1000*CV500*
Reading 255 words *DM to *DM
26.0 21.6
WR2(281) 5 Writing 1 word to word 21.3 17.8 5.40 4.50
Writing 255 words *DM to *DM
27.0 22.5
=(300) 5 Comparing constant and word 14.7 12.3 6.15 5.13
Comparing *DM and *DM
20.1 16.8
=L(301) 5 Comparing constant and word 15.6 13.0
Comparing *DM and *DM
21.0 17.5
=S(302) 5 Comparing constant and word 15.0 12.5
Comparing *DM and *DM
20.4 17.0
=SL(303) 5 Comparing constant and word 15.9 13.3
Comparing *DM and *DM
21.3 17.8
<>(305) 5 Comparing constant and word 14.7 12.3
Comparing *DM and *DM
20.1 16.8
<>L(306) 5 Comparing constant and word 15.6 13.0
Comparing *DM and *DM
21.0 17.5
<>S(307) 5 Comparing constant and word 15.0 12.5
Comparing *DM and *DM
20.4 17.0
<>SL(308) 5 Comparing constant and word 15.9 13.3
Comparing *DM and *DM
21.3 17.8
<(310) 5 Comparing constant and word 14.7 12.3
Comparing *DM and *DM
20.1 16.8
<L(311) 5 Comparing constant and word 15.6 13.0
Comparing *DM and *DM
21.0 17.5
<S(312) 5 Comparing constant and word 15.0 12.5
Comparing *DM and *DM
20.4 17.0
<SL(313) 5 Comparing constant and word 15.9 13.3
Comparing *DM and *DM
21.3 17.8
<=(315) 5 Comparing constant and word 14.7 12.3
Comparing *DM and *DM
20.1 16.8
<=L(316) 5 Comparing constant and word 15.6 13.0
Comparing *DM and *DM
21.0 17.5
<=S(317) 5 Comparing constant and word 15.0 12.5
Comparing *DM and *DM
20.4 17.0
<=SL(318) 5 Comparing constant and word 15.9 13.3
Comparing *DM and *DM
21.3 17.8
>(320) 5 Comparing constant and word 14.7 12.3
Comparing *DM and *DM
20.1 16.8
>L(321) 5 Comparing constant and word 15.6 13.0
Comparing *DM and *DM
21.0 17.5
>S(322) 5 Comparing constant and word 15.0 12.5
Comparing *DM and *DM
20.4 17.0
>SL(323) 5 Comparing constant and word 15.9 13.3
Comparing *DM and *DM
21.3 17.8
>=(325) 5 Comparing constant and word 14.7 12.3
Comparing *DM and *DM
20.1 16.8
>=(326) 5 Comparing constant and word 15.6 13.0
Comparing *DM and *DM
21.0 17.5
*Note: CV500 = CV500 or CVM1-CPU01-EV2; CV1000 = CV1000, CV2000, or CVM1-CPU11/21-EV2
Instruction Execution Times Section 6-4
