483
Instruction
OFF execution time (µs)ON execution time (µs)
ConditionsWords
CV1000*CV500*CV1000*CV500*
>=S(327) 5 Comparing constant and word 15.0 12.5 6.15 5.13
Comparing *DM and *DM
20.4 17.0
>=SL(328) 5 Comparing constant and word 15.9 13.3
Comparing *DM and *DM
21.3 17.8
TST(350) 5 Designating constant for word bit 14.6 12.1
Designating constant for *DM bit
20.4 17.0
TSTN(351) 5 Designating constant for word bit 14.4 12.0
Designating constant for *DM bit
20.3 16.9
+(400) 5 Constant + word → word 16.4 13.6 1.35 1.13
*DM + *DM → *DM
24.0 20.0
+L(401) 5 Constant + word → word 18.5 15.4
*DM + *DM → *DM
26.4 22.0
+C(402) 5 Constant + word → word 8.40 7.00
*DM + *DM → *DM
12.6 10.5
+CL(403) 5 Constant + word → word 10.4 8.63
*DM + *DM → *DM
14.9 12.4
+B(404) 5 Constant + word → word 16.8 14.0
*DM + *DM → *DM
25.7 21.4
+BL(405) 5 Constant + word → word 29.3 24.4
*DM + *DM → *DM
38.0 31.6
+BC(406) 5 Constant + word → word 9.00 7.50
*DM + *DM → *DM
13.8 11.5
+BCL(407) 5 Constant + word → word 21.5 17.9
*DM + *DM → *DM
26.1 21.8
–(410) 5 Constant – word → word 16.7 13.9
*DM – *DM → *DM
24.6 20.5
–L(411) 5 Constant – word → word 18.3 15.3
*DM – *DM → *DM
26.3 21.9
–C(412) 5 Constant – word → word 8.25 6.88
*DM – *DM → *DM
13.4 11.1
–CL(413) 5 Constant – word → word 10.4 8.63
*DM – *DM → *DM
14.6 12.1
–B(414) 5 Constant – word → word 16.5 13.8
*DM – *DM → *DM
25.4 21.1
–BL(415) 5 Constant – word → word 28.7 23.9
*DM – *DM → *DM
36.9 30.8
–BC(416) 5 Constant – word → word 8.85 7.38
*DM – *DM → *DM
13.7 11.4
–BCL(417) 5 Constant – word → word 21.0 17.5
*DM – *DM → *DM
25.2 21.0
*
(420)
5 Constant x word → word 24.9 20.8
*DM x *DM → *DM
34.4 28.6
*
L(421)
5 Constant x word → word 55.4 46.1
*DM x *DM → *DM
66.6 55.5
*
U(422)
5 Constant x word → word 16.2 13.5
*DM x *DM → *DM
20.9 17.4
*Note: CV500 = CV500 or CVM1-CPU01-EV2; CV1000 = CV1000, CV2000, or CVM1-CPU11/21-EV2
Instruction Execution Times Section 6-4
