Omron SYSMAC CV Series - SECTION 7 PC Setup

484
Instruction
OFF execution time (µs)ON execution time (µs)
ConditionsWords
CV1000*CV500*CV1000*CV500*
*
UL(423)
5 Constant x word → word 46.8 39.0 1.35 1.13
*DM x *DM → *DM
54.0 45.0
*
B(424)
5 Constant x word → word 22.1 18.4
*DM x *DM → *DM
27.0 22.5
*
BL(425)
5 Constant x word → word 64.2 53.5
*DM x *DM → *DM
72.2 60.1
/(430) 5 Constant  word → word 27.8 23.1
*DM  *DM → *DM
35.9 29.9
/L(431) 5 Constant  word → word 69.6 58.0
*DM  *DM → *DM
77.6 64.6
/U(432) 5 Constant  word → word 18.9 15.8
*DM  *DM → *DM
22.5 18.8
/UL(433) 5 Constant  word → word 59.7 49.8
*DM  *DM → *DM
63.6 53.0
/B(434) 5 Constant  word → word 20.7 17.3
*DM  *DM → *DM
24.9 20.8
/BL(435) 5 Constant  word → word 75.2 62.6
*DM  *DM → *DM
79.1 65.9
FIX(450) 5 Word → word 335 279 1.2 1.0
*DM → *DM
336 280
FIXL(451) 5 Word → word 413 344
*DM → *DM
413 344
FLT(452) 4 Word → word 327 272
*DM → *DM
332 277
FLTL(453) 5 Word → word 402 335
*DM → *DM
408 340
+F(454) 5 Constant + word → word 421 351
1.35 1.13
*DM + *DM → *DM
429 358
–F(455) 5 Constant – word → word 449 374
*DM – *DM → *DM
457 381
*
F(456)
5 Constant x word → word 436 363
*DM x *DM → *DM
444 370
/F(457) 5 Constant  word → word 481 401
*DM  *DM → *DM
490 408
RAD(458) 5 Word → word 438 365
1.2 1.0
DEG(459) 5 Word → word 438 365
SIN(460) 5 Word → word 2.80 ms 2.34 ms
COS(461) 5 Word → word 2.68 ms 2.23 ms
TAN(462) 5 Word → word 4.31 ms 3.59 ms
ASIN(463) 5 Word → word 4.51 ms 3.76 ms
ACOS(464) 5 Word → word 4.61 ms 3.85 ms
ATAN(465) 5 Word → word 2.18 ms 1.82 ms
SQRT(466) 5 Word → word 890 742
EXP(467) 5 Word → word 4.47 ms 3.72 ms
LOG(468) 5 Word → word 2.25 ms 1.87 ms
BEND<001> 2 --- 4.65 3.88 2.85 2.38
*Note: CV500 = CV500 or CVM1-CPU01-EV2; CV1000 = CV1000, CV2000, or CVM1-CPU11/21-EV2
Instruction Execution Times Section 6-4
