11-10
FP2/FP2SH/FP10SH
Item
Add-
ress
Name
Default
value
Descriptions
Hold/
Non-
hold
5
Counter starting address
(setting the number of
timers and counters)
FP2SH/
FP10SH:
3000
FP2SH/
FP10SH:
0 to 3072
Set the system registers
5 and 6 to the same
value.
FP2:
1000
FP2:
0 to 1024
6
Hold type area starting
address setting for
timer/counter
FP2SH/
FP10SH:
3000
FP2SH/
FP10SH:
0 to 3072
FP2:
1000
FP2:
0 to 1024
7
Hold type area starting
address setting for
internal relays (in word
units)
FP2SH/
FP10SH:
500
FP2SH/FP10SH: 0 to 887
FP2: 200
FP2: 0 to 253
8
Hold type area starting
address setting for data
registers
0
FP2SH/FP10SH: 0 to 10240
FP2: 0 to 6000
9
Hold type area starting
address setting for file
registers (For FP2SH,
bank 0)
0
FP2SH/FP10SH: 0 to 32765
FP2 (16K): 0 to 14333
FP2 (32K): 0 to 30717
10
Hold type area starting
address setting for
MEWNET-W/P link relays
(for PC link 0) (*Note)
0
0 to 64
11
Hold type area starting
address setting for
MEWNET-W/P link relays
(for PC link 1) (*Note)
64
64 to 128
12
Hold type area starting
address setting for
MEWNET-W/P link data
registers (for PC link 0)
(*Note)
0
0 to 128
13
Hold type area starting
address setting for
MEWNET-W/P link data
registers (for PC link 1)
(*Note)
128
128 to 256
14
Hold or non-hold setting
for step ladder process
Non-hold
Hold/non-hold
15
Hold type area starting
address setting for file
register (for bank 1)
0
0 to 32765
Note) Available PLC MEWNET-W: FP10SH, FP2, FP2SH
MEWNET-P: FP10SH
