I/O AllocationFP2/FP2SH
3 − 5
3.1 Fundamentals of I/O Allocation
3.1.2 Table of Occupied I/O Points by Unit
Name Part number Occupied
I/O point
Number of
occupied slot
CPU Standard type CPU FP2−C1 −
1
CPU
CPU with 64 points input FP2−C1D 64X 2
CPU with S-LINK FP2−C1SL (* Note 1) 2(* Note 2)
FP2SH CPU FP2−C2L AFP2221 −
1
FP2SH
CPU
FP2−C2 AFP2231 − 1
FP2−C2P AFP2235 − 1
FP2−C3P AFP2255 − 1
Remote I/O Slave Unit FP2−RMS − 1
Input unit 16-point type DC input FP2−X16D2 16X 1
Input
unit
32-point type DC input FP2−X32D2 32X 1
64-point type DC input FP2−X64D2 64X 1
Output unit 16-point type relay output FP2−Y16R 16Y 1
Output
ut
6-point type relay output FP2−Y6R 16Y 1
16-point type transistor (NPN)
output
FP2−Y16T 16Y 1
16-point type transistor (PNP)
output
FP2−Y16P 16Y 1
32-point type transistor (NPN)
output
FP2−Y32T 32Y 1
32-point type transistor (PNP)
output
FP2−Y32P 32Y 1
64-point type transistor (NPN)
output
FP2−Y64T 64Y 1
64-point type transistor (PNP)
output
FP2−Y64P 64Y 1
I/O mixed unit 32-point type DC input/32-point
type transistor (NPN) output
FP2−XY64D2T
FP2−XY64D7T
32X, 32Y 1
32-point type DC input/32-point
type transistor (PNP) output
FP2−XY64D2P
FP2−XY64D7P
32X, 32Y 1
