I/O AllocationFP2/FP2SH
3 − 11
3.2 Arbitrary Allocation
3.2.3.2 When Using FP2 Backplane H Type
Backup battery
expansion memory
Power supply unit
Power supply unit
Board No. setting switch “1”
Board No. setting switch “2”
Basic backplane
Expansion backplane
Expansion backplane
COM port
Tool port
I/O unit
I/O unit
CPU unit
Basic backplane
Power supply unit: 1 module
I/O units: 16−point type input: 8 units
Expansion backplane No. 1
Power supply unit: 1 module
I/O units: 16−point type output: 8 units
Expansion backplane No. 2
Power supply unit: 1 module
I/O units: 16−point type input: 8 units
Expansion cable
